Series: Fuji Contactor SC series

Features

- Fuji Contactor SC series : Small frame contactors with new functions join the SC series.

- The SC line up, which is based on high level technology, now extends from the SC-03 to the SC-N16.

- The SC series contactors have such options as additional auxiliary contact blocks and operation counter unit with snap-on fittings, and coil surge suppressors.

- Application of Fuji Contactor SC series: Control of all types of motor for standard or severe duty applications. Control of resistive, inductive and capacitive circuits: heating, lighting, cos rectification, transformer, normal-standby.

Specifications

Number of poles	3
Rated current In (A)	5, 7, 9, 11, 12, 13, 15, 16, 17, 18 19, 22, 24,26, 29, 32, 38, 40,48, 50, 64, 65, 72, 80, 85, 90,103, 105, 120, 125, 150, 180, 200, 220, 230, 300, 360, 400, 600, 630, 720, 800
Rated control circuit voltage Uc (V)	24, 48, 100, 100-110, 110-120, 200, 200-220, 220-240, 346-380, 380-400, 415-440, 480-500, 24-25, 48-50, 100-127, 200-250, 265-347, 380-450, 460-575 VAC 24, 48, 100-120, 200-240 VDC
Rated operational voltage Ue (V)	24, 48, 100, 110, 120, 200, 220, 240, 300, 380, 400, 440, 500
Rated insulation voltage Ui (V)	-
Rated impulse withstand voltage Uimp (kV)	-
Auxiliary contact	1NO, 1NC, 1NO+1NC, 2NO, 2NC, 2NO+2NC, 3NO+3NC, 4NO+4NC
Accessories	Trip indicator, Reset release, Base unit for separate mounting, Terminal cover
Standards	EN60947-4-1, IEC60947-4-1, UL, CSA
