Guard lock safety-door switch OMRON D4JL-4RFA-D7-01

7,416,500₫

24VDC; Mechanical lock; Solenoid release; Key holding force: 3000N min.; Trapped key

Manufacturer: OMRON

Item Status: Contact us

Buy fast, cheaper

Customer support hotline for products:

Northern Region, North Central Region:

Email 0989 465 256

0989 465 256

Southern Region, South Central Region:

Email 0936 862 799

0936 862 799

Series: Guard lock safety-door switch Omron D4JL series

Model: D4JL-4RFA-D7-01

Features of Guard lock safety-door switch OMRON D4JL series (contains model D4JL-4RFA-D7-01)

Guard lock safety-door switch OMRON D4JL series:

- Two safety circuits and two monitor contacts provide an array of monitoring patterns.

- Applicable to both standard loads and microloads.

- Models with trapped keys prevent workers from being locked in hazardous work areas.

- Models with rear release buttons allow people to unlock the switch and escape if they are locked into hazardous areas.

- IP67 degree of protection.

Specifications of Guard lock safety-door switch OMRON D4JL-4RFA-D7-01

Type	Guard lock safety door switches
Actuator style	Key
Power supply voltage	24VDC
Door monitor contact configuration	3NC
Lock monitor contact configuration	3NC
Contact type	Slow action
Contact capacity	3A at 240VAC, 0.27A at 250VDC
Indicator type	LED indicator
Key insertion direction	Horizontal, Vertical
Door lock type	Mechanical lock
Door release type	Solenoid release
Key holding force	3000N min.
Release key type	Trapped key
Key insertion force	20N max.
Key extraction force Max.	20N max.
Key pretravel (PT)	14mm max.
Key movement before being locked	3.3mm min.
Cable entry	M20 conduit (2 port)
Electric connection method	Screw terminal
Head material	Plastic
Housing material	Plastic
Key material	Metal
Ambient temperature	-10...55°C
Ambient humidity	95% max.
Degree of protection	IP67
Representative standard	CE, CCC, CUL, S-Mark, UL
Keys (Sold sparately)	D4JL-K1, D4JL-K2, D4JL-K3

Installation guide Guard lock safety-door switch OMRON Contact mailbox baoan@baoanjsc.com.vn or phone number 0989 465 256

Document of Guard lock safety-door switch OMRON

Guard-lock-safety-door-switch-OMRON-D4JL-ser.pdf

Guard-lock-safety-door-switch-OMRON-D4JL-series.pdf
